7/16″ Commercial Flush Bolt Guide For Heavy-Duty Doors

Description

The Commercial Door Flush Bolt Guide – 7/16″ Width Replacement Guide is designed to help maintain proper alignment and smooth operation of flush bolts used in commercial door systems. This guide keeps the bolt centered within the door edge, allowing it to extend and retract smoothly when securing or releasing the inactive door panel.

Height: 1-7/16″
Width: 7/16″
Back Squared Hole Height: 3/8″
Material: Plastic
Compatibility: CH-139 Flush Bolt
Part Number: CH-138

Constructed from durable plastic, the guide helps reduce friction and wear on the flush bolt while ensuring consistent engagement with the strike or floor socket. It is designed to be compatible with the CH-139 flush bolt, making it a reliable replacement component when the original guide becomes worn, damaged, or missing.

With a height of 1-7/16″ and width of 7/16″, this guide is sized to fit compatible commercial flush bolt assemblies commonly used on double doors in offices, storefronts, and other commercial buildings. The back squared hole measures 3/8″ in height, helping maintain proper bolt alignment during operation.

Replacing a worn guide can help restore smooth flush bolt function and extend the life of the door hardware.
